JAVA中几种常用的RPC框架介绍

释放双眼,带上耳机,听听看~!

浅谈服务治理与微服务 http://blog.csdn.net/suifeng3051/article/details/53992560

  1. RPC框架可以从语言兼容和服务治理不同角度来划分:

从语言兼容上的rpc框架有 thrift zeroC-ICE protbuf

从服务治理角度的rpc架构有 dubbo RMI、Hessian spring Cloud





所谓服务治理,主要包括服务发现、负载均衡、容错、日志收集等功能

1.dubbo:

 使用Hessian的序列化协议,传输则是TCP协议,使用了高性能的NIO框架Netty



JAVA中几种常用的RPC框架介绍

服务接口


1
public
interface
DemoService {
2
String sayHello(String name);
3 }

服务实现


1
2
3
4
5
6
11 public class DemoServiceImpl implements DemoService {
22     public String sayHello(String name) {
33         return "Hello " + name;
44     }
55 }
6

Configure service provider

The code snippet below shows how a dubbo service provider is configured with spring framework, which is recommended, however you could also use API configuration if it’s preferred.


1
2
3
4
5
6
7
8
9
10
11
12
11 <?xml version="1.0" encoding="UTF-8"?>
2 2 <beans xmlns="http://www.springframework.org/schema/beans"
3 3        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
4 4        xmlns:dubbo="http://code.alibabatech.com/schema/dubbo"
5 5        xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://code.alibabatech.com/schema/dubbo http://code.alibabatech.com/schema/dubbo/dubbo.xsd">
6 6     <dubbo:application name="demo-provider"/>
7 7     <dubbo:registry address="multicast://224.5.6.7:1234"/>
8 8     <dubbo:protocol name="dubbo" port="20880"/>
9 9     <dubbo:service interface="com.alibaba.dubbo.demo.DemoService" ref="demoService"/>
1010     <bean id="demoService" class="com.alibaba.dubbo.demo.provider.DemoServiceImpl"/>
1111 </beans>
12

Start service provider


1
2
3
4
5
6
7
8
9
11 public class Provider {
22     public static void main(String[] args) throws Exception {
33         ClassPathXmlApplicationContext context = new ClassPathXmlApplicationContext(
44                 new String[] {"META-INF/spring/dubbo-demo-provider.xml"});
55         context.start();
66         System.in.read(); // press any key to exit
77     }
88 }
9

Configure service consumer


1
2
3
4
5
6
7
8
9
10
11 <?xml version="1.0" encoding="UTF-8"?>
22 <beans xmlns="http://www.springframework.org/schema/beans"
33        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
44        xmlns:dubbo="http://code.alibabatech.com/schema/dubbo"
55        xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd http://code.alibabatech.com/schema/dubbo http://code.alibabatech.com/schema/dubbo/dubbo.xsd">
66     <dubbo:application name="demo-consumer"/>
77     <dubbo:registry address="multicast://224.5.6.7:1234"/>
88     <dubbo:reference id="demoService" interface="com.alibaba.dubbo.demo.DemoService"/>
99 </beans>
10

Run service consumer


1
2
3
4
5
6
7
8
9
10
11
11 public class Consumer {
2 2     public static void main(String[] args) throws Exception {
3 3         ClassPathXmlApplicationContext context = new ClassPathXmlApplicationContext(
4 4                 new String[]{"META-INF/spring/dubbo-demo-consumer.xml"});
5 5         context.start();
6 6         DemoService demoService = (DemoService) context.getBean("demoService"); // obtain proxy object for remote invocation
7 7         String hello = demoService.sayHello("world"); // execute remote invocation
8 8         System.out.println(hello); // show the result
9 9     }
1010 }
11



2.RMI

  • 实现结构图



对外接口:


1
2
3
4
5
6
11 public interface IService extends Remote {
22
33          public String queryName(String no) throws RemoteException;
44
55      }
6

接口实现


1
2
3
4
5
6
7
8
9
10
11 public class ServiceImpl extends UnicastRemoteObject implements IService {
2 2
317     @Override
418     public String queryName(String no) throws RemoteException {
519         // 方法的具体实现
620         System.out.println("hello" + no);
721         return String.valueOf(System.currentTimeMillis());
822     }
9
10

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
11 // RMI客户端
2 2 public class Client {
3 3
4 4     public static void main(String[] args) {
5 5         // 注册管理器
6 6         Registry registry = null;
7 7         try {
8 8             // 获取服务注册管理器
9 9             registry = LocateRegistry.getRegistry("127.0.0.1",8088);
1010             // 列出所有注册的服务
1111             String[] list = registry.list();
1212             for(String s : list){
1313                 System.out.println(s);
1414             }
1515         } catch (RemoteException e) {
1616
1717         }
1818         try {
1919             // 根据命名获取服务
2020             IService server = (IService) registry.lookup("vince");
2121             // 调用远程方法
2222             String result = server.queryName("ha ha ha ha");
2323             // 输出调用结果
2424             System.out.println("result from remote : " + result);
2525         }32     }
2633 }
27




1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
11 // RMI服务端
2 2 public class Server {
3 3
4 4     public static void main(String[] args) {
5 5         // 注册管理器
6 6         Registry registry = null;
7 8             // 创建一个服务注册管理器
8 9             registry = LocateRegistry.createRegistry(8088);
915             // 创建一个服务
1016             ServiceImpl server = new ServiceImpl();
1117             // 将服务绑定命名
1218             registry.rebind("vince", server);
13 23         }
1424     }
1525 }
16

3.Hessian

基于HTTP的远程方法调用,在性能方面还不够完美,负载均衡和失效转移依赖于应用的负载均衡器,Hessian的使用则与RMI类似,区别在于淡化了Registry的角色,通过显示的地址调用,利用HessianProxyFactory根据配置的地址create一个代理对象,另外还要引入Hessian的Jar包。
